The most efficient spiral micro-bubbles vent valve

Characteristics:

The gas content in the circulating water system can be removed more than 95% after three hours operation with a flow velocity of 1m/s.(Laboratory test data)

Maximum working temperature: 110℃, maximum allowable working pressure: 16bar; the maximum customizable design conditions are 180℃ or 25bar.

For water and water/glycol mixtures (max. 50% glycol).

Horizontal installation or vertical installation. Threaded connection and exclusion seal.

The minimum diameter of removed air bubbles is 10μm.

The product meets CE standard.

General construction, built-in copper filter element with helical structure, and the body is made of brass.
